J61锻钢截止阀 |
|
J61锻钢截止阀设计与制造标准:
设计与制造:BS1873 BS5160 法兰尺寸:ANSIB16.5 压力温度:ANSIB16.34 结构长度:ANSIB16.10 BS1873 对焊连接尺寸:ANSIB16.25 检验与实验:BS6755
J61锻钢截止阀安装尺寸及重量:
ANSI 150Lb |
NPS |
1/2 |
3/4 |
1 |
11/4 |
11/2 |
2 |
L |
108 |
117 |
127 |
140 |
165 |
203 |
H |
165 |
195 |
250 |
250 |
290 |
310 |
D0 |
100 |
125 |
160 |
160 |
180 |
200 |
Wt |
6.9 |
9.8 |
13.5 |
19.5 |
28.5 |
30.3 |
ANSI 300Lb |
NPS |
1/2 |
3/4 |
1 |
11/4 |
11/2 |
2 |
L |
152 |
178 |
203 |
216 |
229 |
267 |
H |
165 |
195 |
250 |
250 |
290 |
310 |
D0 |
100 |
125 |
160 |
160 |
180 |
200 |
Wt |
7.7 |
11.3 |
16.8 |
21.2 |
32.6 |
35 |
ANSI 600Lb |
NPS |
1/2 |
3/4 |
1 |
11/4 |
11/2 |
2 |
L |
165 |
190 |
216 |
229 |
241 |
292 |
H |
165 |
195 |
250 |
250 |
290 |
310 |
D0 |
100 |
125 |
160 |
160 |
180 |
200 |
Wt |
7.8 |
12.5 |
17.5 |
23.5 |
38.5 |
42.2 |
ANSI 150Lb-800Lb |
NPS |
1/4 |
3/8 |
1/2 |
3/4 |
1 |
11/4 |
11/2 |
2 |
L |
79 |
79 |
79 |
92 |
111 |
120 |
152 |
172 |
H |
155 |
155 |
155 |
160 |
195 |
165 |
265 |
300 |
D0 |
100 |
100 |
100 |
100 |
125 |
160 |
160 |
180 |
Wt |
2.2 |
2.2 |
2.0 |
1.9 |
2.4 |
3.5 |
8.0 |
8.6 | |
|
|
|
